CITA SMART 22 Commercial Premium Ev Charger

Name: CITA SMART 22 Commercial Premium Ev Charger
Brand: CITA
SKU: CITA22COM
Price: 1249.0 GBP
Availability: InStock

Store / DEVELOPERS

£1,249.00

Price incl. VAT (0%) £0.00

Installation Service

Domestic Installation ( +£395.00 )

Commercial Installation ( +£495.00 )

Installation Date

Please choose a date

Booking Notes

Enter your text

In stock

Product Details

UPC: CS7HO

Brand: CITA

CITA Commercial EV Charging Solutions

With a rise in electric vehicles across the UK, supporting infrastructure such as DC EV charging stations have started to show up in commercial areas. CITA EV aims to offer you safe, high-quality, yet simple commercial electric car charger range. These chargers include a wide range of features, integrating innovative, state-of-the-art technology with easy-to-use, compact designs. You can also use our mobile app to connect with the EV charger and access it from anywhere.

CITA Smart 22 commercial charger provides fast charging to an electric vehicle, using the chargers on-board three-phase supply. Compliant with the industrial standards, the charger use MID certified meter to ensure accuracy and built-in RCD to secure the safety. Smart 22 can be connected to a charging network with the help of CITA Charger Management System portal.

CITA Connect App

You are powered by a smart application to manage all your CITA Smart 7 monitoring and settings from your iOS or Android mobile phone.

General Specifications

Charging Socket	IEC 62196 Type 2, IP54, locking
Charging Mode	Mode 3 (IEC 61851-1 / SAE J1772 compliant communication protocol)
6mA DC Trip	Integrated
IP Rating	IP54
Operating Temperature	- 30~ + 50°C
Product Dimension	300mm x 300mm x 130mm

AC Nominal Input/Output

Phases/Lines	3 phase + netural+ PE
Voltage	400V±10% AC
Frequency	50/60Hz

AC Nominal Output

Voltage	400V±10% AC
Output Power	22kW
Output Current	6 - 32A programmable

Protection

Active Load Management	Yes, with external CT clamp (100A max)
Dynamic Load Balancing	Yes, via CITA cloud software
Warranty	3-years

Communication

Communication Method	WiFi, Optional: 4G/Ethernet
Mobile App Availability	Yes, Android and iOS App
Communication Protocol	OCPP 1.6 - JSON

About CITA

With a drive to make mobility 100% green, CITA EV is innovating towards powering a green future. We bring to you an EV charging experience that is simple, safe and smart. Our innovative design has made our product into a compact unit that is easily installable at homes and businesses alike. A team of experts have put their best tech minds together at CITA to make the communication between you and your charger as easy as possible. We have developed an application for the same that ensures maximum charging capability with minimal effort.

CITA EV is equipped to provide world-class charging solutions for homes, businesses and cities. With offices in the U.K. UAE and the USA, the progressive global presence of CITA EV chargers is now apparent, with partnerships covering Europe, the USA and the MENA region.
